As you are already aware that we at Trinity Touch, have been focusing on providing innovative solutions for the infrastructures and power sector, we are pleased to inform you that Trinity Touch has successfully completed the customized solutions for the Metro projects.
In Line with our commitment to provide clean and environmental friendly solutions for power generation, Trinity Touch has been focusing on the Solar and Wind Energy Sectors and has successfully provided customized solutions (Array/String Junction boxes, Main Junction Boxes, Sub main Junction Boxes, AC Distribution Boards, DC Distribution Boards etc.) for the various Solar Farm Projects across the country.
For more information please log on to: www.trinitytouch.com
About Us
Trinity Touch has emerged as one of the leading companies engaged in manufacturing, assembly and distribution activities providing value added services to its customers. Trinity Touch has its presence in the United Kingdom and India currently.
Trinity Touch’s business involves seeking out manufacturers and designers of products from all over the world for solutions best suited for the market. Trinity Touch carries forward this task to bring the right solution for the customer at the right price and right time. Trinity Touch has managed to form a portfolio of principle companies, which are one of the market leaders in their respective fields.
Trinity Touch operates a decentralised business philosophy through which the local managers make all the day-to-day decisions. The highly trained team offers unbiased advice to find the best solution for the customers’ needs. This management style helps to build relationships with customers and suppliers locally for everyone’s benefit.
We are pleased to announce that Trinity Touch (P) Ltd. has tied up with Bulgin, UK for introducing their product range in India. We feel glad to inform that we are the only authorised distributor in India who deals in Indian currency maintaining stock for the front running Fuse Holders especially their PC Mounting series.
Fuseholders
 Bulgin’s extensive range of fuseholders are designed to give the degree of protection demanded in today’s sophisticated electronic equipment. Carrying world-wide safety approvals from UL, VDE, CSA, SEMKO and IMQ, all types are manufactured from high grade flame retardant nylon and polyester materials.
Designed primarily for 5 x 20mm and 6.3 x 32mm size fuses with protection against shock to categories PC1, PC2 and PC3. There’s a choice of styles for in-line, PCB mounting and panel mounting (screw or snap fit) with terminal options for solder, 2.8mm, 4.8mm or 6.3mm tabs or PC spills.
Dust and waterproof designs provide a front of panel seal to IP68 in both 5 x 20mm and 6.3 x 32mm size fuses.
Fuse carrier styles include captive drawer, screw cap – with screw driver release, bayonet cap – with screw driver release and screw cap – with finger release.
In- Line Fuseholders
FX0180, FX0280, FX0380
- • Protection Category PC1
- • Fuse Sizes 5 x 20mm, 6.3 x 25mm and 6.3 x 32mm
- • Screw Terminal (Solder to order)
- • 10A, 50V (250V Inaccessible)
- • UL Approved
- • Clear or black
- • RoHS Compliant
FX0185, FX0285, FX0385
- • Sealed to IP66
- • Protection Category PC1
- • Fuse Sizes 5 x 20mm, 6.3 x 25mm and 6.3 x 32mm
- • Screw Terminal (Solder to order)
- • 10A, 50V (250V Inaccessible)
- • UL Approved
- • Clear or black
- • RoHS Compliant
Base Mounting
FX0321
- • Base Mount
- • Category PC1
- • Fuse Sizes 5 x 20mm
- • PC Spills
- • 6.3A, 250V
- • RoHS Compliant
PC Mounting
FX0456 & FX0457
- • PC Horizontal and Vertical Mount
- • Touchproof Category PC2
- • Fuse Sizes 5 x 20mm
- • Bayonet Cap/Screwdriver Release
- • 10A, 250V
- • VDE, UL, CSA, SEMKO & IMQ approvals
- • RoHS Compliant
For more information please log on to: www.trinitytouch.com
About Us
Trinity Touch has emerged as one of the leading companies engaged in manufacturing, assembly and distribution activities providing value added services to its customers. Trinity Touch has its presence in the United Kingdom and India currently.
Trinity Touch’s business involves seeking out manufacturers and designers of products from all over the world for solutions best suited for the market. Trinity Touch carries forward this task to bring the right solution for the customer at the right price and right time. Trinity Touch has managed to form a portfolio of principle companies, which are one of the market leaders in their respective fields.
Trinity Touch operates a decentralised business philosophy through which the local managers make all the day-to-day decisions. The highly trained team offers unbiased advice to find the best solution for the customers’ needs. This management style helps to build relationships with customers and suppliers locally for everyone’s benefit.
Excitation with Time control by impulse ans sustained propagation speed
Saint Elme Active 2D lightning conductor remote control tester:
The Saint Elme Active 2D® lightning conductor can be tested on site, with its
remote control tester (initial checking, periodic checking in compliance with
NFC 17 – 102 and decrees in force, maintenance,…)
Simple and fast, the test does not require any particular operation of lightning
conductor dismounting and can be done safety from the ground.
Active 2D® remote control testers use the communication by Radio waves, and
create any electromagnetic perturbation.
Saint Elme Active 2D® lightning conductors and their testers are both
equipped with one transmitter / receiver : bi- directional emission and
reception.
| Reference |
Designation |
Weight
(kg) |
Size
(cm) |
| AFV0100TT |
Remote Control Tester |
0,5 |
65 x 130 x 25 |
| AFV1000TT |
Activ’Test® Remote control Tester |
1 |
70 x 135 x 25 |
| AFV0005TT |
5 units Recharging for Activ’Test® |
- |
- |
AFV0100TT Remote Control Tester
AFV0100TT Remote Control Tester allows to check the operating of
the Active 2D® lightning conductor.
The supply of this tester is insured by battery (included).
The signal system by LED indicates immediately the obtained result
(Positive or negative).
Effective working
until 100 m of distance
The test guarantees
that the lightning
conductor is ready to
work.

Activ’Test AFV1000TT Remote Control Tester
• Digital screen 128 x 64 pixels
• Checking of the functioning of the Active 2D selected
•Programming until 25 Active 2D®lightning conductors; serial number
programmed in advance in the factory – the 10 first numbers are
offered at each tester order *
• Storage until 3200 registrations, with the date and hour, thanks to the microcontroller FLASH memory and EEProm memory.
• Possibility of analyzing the values stored in factory (battery voltage,
capacitor voltage, solar or wind voltage system, interior temperature of
the carter…), sending by email the file **
• Additional serial numbers is possible via a recharging of 5 numbers:
ref AFV0005TT
• Delivered with software enables to forward, to download the
updated data via USB port directly on a computer
The supply of the AFV1000TT tester is insured by a reloading battery with cable
USB (included) or by normal battery.
It is possible, always via USB and adapter (none included) to load Activ’Test® thanks to a car cigar-lighter.
* If the 10 numbers are not written in the order, the missing numbers are lost
** Paying service
*** Cigar-lighter adapter no included
For more information please log on to: www.trinitytouch.com
About Us
Trinity Touch has emerged as one of the leading companies engaged in manufacturing, assembly and distribution activities providing value added services to its customers. Trinity Touch has its presence in the United Kingdom and India currently.
Trinity Touch’s business involves seeking out manufacturers and designers of products from all over the world for solutions best suited for the market. Trinity Touch carries forward this task to bring the right solution for the customer at the right price and right time. Trinity Touch has managed to form a portfolio of principle companies, which are one of the market leaders in their respective fields.
Trinity Touch operates a decentralised business philosophy through which the local managers make all the day-to-day decisions. The highly trained team offers unbiased advice to find the best solution for the customers’ needs. This management style helps to build relationships with customers and suppliers locally for everyone’s benefit.
We are pleased to announce that Trinity Touch has been awarded with CE mark on G type DIN rail by CII India.
All the variants of G type DIN rail are covered under this certification in accordance to IEC 60715
Covered product details are as below :
| Type |
Size |
Plating Range |
| Perforated |
32/15 |
TDR2,TDR3,TBLS |
| Un-perforated |
32/15 |
TDR2,TDR3,TBLS |
If you require samples or further information, do not hesitate to contact us. We will be pleased to assist you!
For more information please log on to: www.trinitytouch.com
About Us
Trinity Touch has emerged as one of the leading companies engaged in manufacturing, assembly and distribution activities providing value added services to its customers. Trinity Touch has its presence in the United Kingdom and India currently.
Trinity Touch’s business involves seeking out manufacturers and designers of products from all over the world for solutions best suited for the market. Trinity Touch carries forward this task to bring the right solution for the customer at the right price and right time. Trinity Touch has managed to form a portfolio of principle companies, which are one of the market leaders in their respective fields.
Trinity Touch operates a decentralised business philosophy through which the local managers make all the day-to-day decisions. The highly trained team offers unbiased advice to find the best solution for the customers’ needs. This management style helps to build relationships with customers and suppliers locally for everyone’s benefit.
Early Streamer Emission
Principle & operating
The ACTIVE 1D excitation advance is obtained by a device
named, " impulse device ". Its principle consists in storing
electrostatic energy present in the Atmosphere at a stormy
cloud approach, to release the ascending discharge excitation
in good time.
This device operates at a stormy activity approach by an integrated
sensor which measures the surrounding electrical field
value.
It provokes then a polarity inversion of the lightning conductor
head, creating a sudden amplification of the electrical
field on its tip.
Active 1D Features:
• Consider the energetic parameter to choose the streamer
which has the capacity to become an ascending leader,
• Autonomous and clean energy source: Atmospheric electrical field,
• Cloud polarity consideration,
• Head curve radius optimized to reduce the Corona effect and guarantee the excitation device,
• Functioning warranty in any atmospheric condition,
• High resistance to the corrosion thanks to its 100% manufacture in 304L stainless steel.
Active 1D radius of protection:
The Early Streamer Emission (ESE) ACTIVE 1D® lightning conductor has been tested in laboratories in compliance with NF C 17-102 standard protocol. These tests have determined an excitation advance of 12μs
with regard to a simple rod.
The ACTIVE 1D® radii of protection here below mentioned, are defined for the three
Np levels of protection (from I to IV) depending on the height h between lightning
conductor tip and the structure highest point to protect.
ΔT : Excitation Advance, for the ACTIVE 1D®, ΔT = 12μs,
- Np: Level of protection with different severity levels (I to IV) determined by lightning risk assessment. IEC 62305-2 standard,
- h(m): Height between the lightning conductor tip and the highest point to protect.
| Rp |
Active 1D, ΔT = 12μS |
| H(m) |
40%* |
I |
II |
III |
IV |
| 2 |
7 |
11 |
13 |
16 |
19 |
| 3 |
10 |
17 |
20 |
24 |
28 |
| 4 |
14 |
23 |
27 |
32 |
37 |
| 5 |
17 |
28 |
34 |
41 |
46 |
| 6 |
17 |
29 |
34 |
42 |
48 |
| 8 |
18 |
30 |
36 |
43 |
50 |
| 10 |
18 |
30 |
37 |
45 |
52 |
| 20 |
19 |
32 |
41 |
51 |
60 |
| 30 |
19 |
32 |
42 |
55 |
65 |
| 60 |
19 |
32 |
42 |
57 |
72 |
Active 1D range of products:
| Range |
ΔT(μs) |
Lightning counter |
| AFB10121D |
12 |
Not included |
| AFB17121D |
12 |
Included |
Packaging
Complete lightning conductor conditioned in carton box.
• Weight: 3.0 Kg
• Dimensions: 430 x 110 x 110 mm
